Product Detail |
Model Number |
FY-YQWPF-10 FY-YQWPF-11 |
Product Name |
Propane Gas Regulator |
Material |
Brass |
Gas |
Propane |
Input Pressure |
1.6Mpa |
Working Pressure |
0.01-0.1Mpa |
Flow |
5M3/h |
Customized Support |
OEM, ODM, OBM |
Place of Origin |
China |
Warranty |
3 Months - 1 Year |
Type Details |
|
|
|
|
Product |
Model |
Inlet Connection |
Outlet Connection |
Feature |
|
YQWPF-10 |
W21.8 |
G3/8 |
Brass Body; Available for customization |
|
YQWPF-11 |
W21.8 LH |
G3/8 LH |
Xiaogalao;Brass Body; Available for customization |
Features |
Xiaogalao Type as a nickname for this product. Gas regulator is mainly used for support cutting and welding process for stable gas outlet. We have many types of gas regulators for diverse gas and standards in different countries. |
This Italian Type Propane Regulator Lpg Brass Body Regulator Yqwpf-10&Yqwpf-11(Xiaogalao) is made of brass. The gas pressure from the liquid supply line is reduced to make gas flow out smoothly. This product is mainly used to meet the requirements for pipeline transportation and storage of propane.
It is a gas control valve that controls both flow and pressure of propane. It also ensures accurate adjustment to cut off the gas supply if any abnormal situation happens. It is suitable for many propane applications like heater, hot plate, water heater, barbecue and more.
The Italian Type Propane Regulator is made from high quality material, which makes it strong and durable. Our propane regulator is easy to install and easy to use with an adjustable range. It also has brass body and packing material, which ensures excellent performance.
The propane regulator is an important part in propane system. It's designed for the pressure control of LPG equipment. The main purpose of this product is to reduce the pressure from a high source to a low pressure level needed by downstream devices. The regulator consists of bonnet and body, which are connected together and work as one unit. While body is fixed to the input pipes, bonnet is telescopic adjustable inside body; when turn handle clockwise, piston moves down to cut off high-pressure gas so as to reduce flow rate and/or cut off completely and let output go directly into atmosphere when turn handle counter clockwise.
